Perfect for the studio or a small club, the AV30 is a fully-featured analog amp that packs decades worth of tones into a compact package. The AV30’s unique multi-circuit analog pre-amp utilizes a 12AX7 tube to provide a full complement of clean, crunch, overdrive, and high gain tones that can be tailored to your liking via the Bright and Fat switches. These classic tones are further enhanced by a customizable, tube equipped analog power section and a unique, sealed speaker enclosure for improved resonance. Rounding out the feature set are three, analog-voiced digital effects including Chorus, Delay & Reverb. The AV30 from VOX is an incredibly versatile amplifier that is packed with pure, analog tone.

With a pair of 12AX7 tubes and eight true analog pre-amp circuits under the hood, VOX’s AV30 delivers robust guitar tones reminiscent of the most coveted amplifiers of all time with enough volume for the stage or the studio.

• Achieve authentic tones with eight, all-analog pre-amp circuits
• 30 Watts of power through a custom VOX 10” speaker
• True analog circuit design complete with two 12AX7 tubes

Pre Amp Circuit:
eight (CLEAN1, CLEAN2, CRUNCH1, CRUNCH2, OD1, OD2, H.GAIN1, H.GAIN2)





Tube:
12AX7 x 2





Effects:
Three (MOD, DELAY, REVERB)

Input/output Jacks:
INPUT, FOOT SW, AUX IN, PHONES, FX LOOP, EXTERNAL SPEAKER

Power Amp Output:
Maximum approx. 30W RMS @4 ohms

Speaker:
VOX original 10" 4 ohms

Power Supply:
Local Voltage





Power Consumption:
27W

Dimensions (W x D x H):
513 × 247 × 474 mm / 20.20" x 9.72" x 18.66"

Weight:
12 kg / 26.46 lbs.

Included Items:
AC cable
